Create Thiessen polygons to sectionalize the service area. Transfer the hydraulic junction information into ArcView. This presentation describes the methods used to: Create a WaterCAD hydraulic model. GIS provides a common link between the different types of available information to assist and support our hydraulic model, master planning, as well as system design and operation decisions. New Information management technology is allowing us to interface independent information systems and applications.

Water cad software#

* WaterNET-CAD download link provides trial version of the software.Capturing the power of ArcView, Avenue, Spatial Analyst and WaterCAD in order to automate, gather, and record data Authors' Names:Įngineering Assistant / Hydraulic Model AnalystĬapturing the power of ArcView, Avenue, Spatial Analyst and WaterCAD in order to automate, gather, and record dataĭevelopment of a Geographic Information System (GIS) automated application to transfer, calculate, and summarize values and information between a water utility GIS database in ArcView, IBM AS400 service address database, and the WaterCAD hydraulic modeling software to determine precise service boundaries based on elevation to support master planning and for design, maintenance, and operations.

Water cad free#

Free product support from specialist civil engineers with great experience in pipes network projects. All the design data are stored in a single *. Reports for bill of quantities (BOQ) and hydraulic computations.g additional pavement layer) you can organize each terrain surface in separate layer and design the network for all future cases. If you have terrain surface that is to be changed in later time (e. The program reads faces from a user defined layer. Quality hydraulic calculation based on EPANET and EPA SWMM computational libraries.Quick and accurate modeling even for large networks having thousants of pipes and nodes.

The program automatically divide the building polygons (basins) based on bisector in each angle and assign the corresonding influence area to nearest pipe. The program includes 'Polyline to pipe' command in order to quick create network from existing drawings.

Each pipe is defined as a single polyline in the drawing.

Quick and easy insertion and modification of network geometry using graphic object modification commands, properties dialog or grips.

Trenches sections based on backfill material and pavement restoration type.

Design drawings for pipes connectivity in plan, profiles for all branches in network.

Export / Import of drawings with file format like DWG and DXF.

The program includes a great number of well known commands to edit graphic objects such as (Copy, Move, Rotate, Offset, trim etc).

Complete and robust solution for designing all types of pipes network projects within rich CAD environment.

Hydraulic calculation based on EPANET and SWMM computational libraries.

Integrated within rich CAD environment.

Design for sewer, vacuum sewer, water distribution and stormwater network facilities.

Autonomous software organized in modules.

Include a number of powerful functions for hydraulic network analysis integrated in a rich CAD environment involving all well known (2D) CAD commands for drawing production. The WaterNET-CAD is software product that can be used in order to create, edit and analyze any kind of sewer, water distribution, storm or vacuum sewer network facility.
